“Cassinella”

2007 Arno Leopard 101’

- Continue Scrolling - or - Click A Link Below -

Photo Gallery

General Arrangement

Information

About the Yard:

Motor yacht "Cassinella" was built at the Arno Shipyard in Pisa, Italy. This esteemed yard was founded in the seventeenth century by the legendary Picchiotti family and ever since Leopard yachts have been renowned for their quality and sportsmanship. The hull is synonyms with performance and speed and they are recognized by the industry for their highly appreciated navigation qualities. "Cassinella" was delivered in 2007 after being designed by Andrea Bacigalupo and represents hull number four of the Leopard brands stunning 31m range. "Cassinella" is ready to cruise and promises to deliver you an exiting ride and life style while aboard. She is sure to impress and the photos and videos are just the beginning. Schedule to see her today, she wont last long..

About The Yacht:

  • Builder: Arno Leopard

  • HIN: C.NE 31/04

  • Official Number: 1276891

  • LOA: 101 ft 8 in

  • Beam: 23 ft

  • Max Draft: 3 ft 5 in

  • Fuel Tanks Capacity: 2522 gal

  • Number of Fuel Tanks: 2

  • Fresh Water Tanks Capacity: 396 gal

  • Number of Fresh Water Tanks: 1

  • Holding Tank Capacity: 224 gal

  • Number of Holding Tanks: 1

  • Displacement: 204,000 LBS

  • Net Tonnage

  • Engine Make: MTU

  • Engine Model: M93 12v2000

  • Drive Type: Jet Drive

  • Engine Year: 2007

  • Hours: 2100

  • Power: 1800 hp x (3)

  • Engine Hours - Port: 2450 Starboard: 2425 Center: 1650 (October 2021)

  • Engine Serials - Port: 535 105 843 Starboard: 535 105 842 Center: 535 105 844

  • Transmission: ZF 3050

  • Low Cruise Speed: 21 knots at 1800 rpm

  • Fast Cruise Speed: 30 knots at 2100 rpm

  • Wide Open: 37 knots reported at 2450 rpm

  • Range: Roughly 430 nautical miles + at 30 knots & 2000 rpm

  • Fuel Burn: 2100 rpm at 30 knots burns 215 liters (168 Gallons) per hour

  • Designer: Andrea Bacigalupo

  • Generators: (2) Kohler 33kW

  • Generator Hours - Port: 9250 Starboard: 10200(October 2021)

  • Generator Serials - Port: 2126062 Starboard: 2123257

Notable Features:

  • Triple MTU engines coupled to Rolls Royce jet drives

  • Shallow draft

  • Fast with a cruise of 30kts and a wide open of almost 37 kts

  • (4) Stateroom and (4) head layout + Crew

  • Low hours on her MTUs (2050 of 12/16/2019)

  • Modern white and acrylic decor package mimicking a W Hotel

  • (4) Crew in (2) rooms with (2) heads

  • Spacious engine room

  • ABT Hydraulic bow thruster

  • Tender garage

  • Camera system for aft, interior salon & engine room

  • Watermaker

Galley Equipment:

  • Miele Convection Microwave

  • (3) Stainless steel Hobart paneled and stainless steel lined refrigerators

  • (3) Stainless steel Hobart paneled and stainless steel lined freexers

  • Miele Professional G7855 stainless steel paneled dishwasher

  • Gaggenau stainless steel paneled oven

  • Newform faucet

  • Miele (6) burner ceramic stove top

  • Stainless steel sink basin with disposal

  • Oven exhaust fan hood

  • LED Lighting recessed overhead

  • Dedicated BOSE speakers and sound system

Work in 2021:

Technical:

  • Complete overhaul of the garage hydraulic rams

  • Overhaul of bow thruster

  • Replaced housings and walls for saloon sky lights

  • Complete bottom job down to raw glass to be made as if new from factory

  • Complete service to fire system

  • New daybed toilet

  • Removed bidet in master head

  • Updated vent fan for engine room

  • Power blinds services and parts replaced

  • Upgraded master stateroom power receptacles to 120v

  • Service crash pump

  • Windows reefed and re-caulked

  • All new exterior cushions

  • All new throw pillows

  • Interior acrylic walls touched up with fresh paint

  • Saloon side doors removed fully serviced and repainted

  • New aft awning canopy

  • New forward awning canopy

  • Cleaned and re-engineered garage to accommodate (2) jet skis instead of one and freeing up the swim platform

  • Rebuilt hydraulic swim ladder

  • Refinished exterior paintwork (not a full paint job)

  • Fresh buff and wax (October 2020)

  • avigation light mast repainted

  • Life rafts fully serviced

  • (2) New barstools in saloon

  • New underwater lights

  • New batteries

AC System:

  • New Frigomar handler in galley

  • New Frigomar handler in master cabin

  • New Frigomar handler in twin room

  • (2) New Frigomar handlers in saloon

  • New seawater pump

  • Full service to chillers

 Engine & Jets:

  • Engines received full 2000 hour service

  • Rolls Royce KEMEWA jet drives sand blasted and painted

  • Full service to both generators

Galley:

  • Parts replaced and service to refrigeration

  • Parts replaced and service to freezers

Electronics:

  • All new Furuno electronics utilizing existing Simrad monitors

  • New Fununo compact dome satellite compass

  • Furuno NEMA 2K2 interface converter

  • New Furuno TZT2BB NavNet Black Box for Radar with color sounder

  • Furuno Radar 25 WATT 96 nautical mile

  • Thru hull digital sounder

  • Garmin Marine VHF

Work in 2018:

  • Port KEMEWA Jet drive fully overhauled

  • Passerelle/Davit completely overhauled

  • New battery chargers
