“ATLANTIC”
1998 Westport 108’
- Continue Scrolling - or - Click a Link Below -
Vessel Technical Information
Builder: Wesport
Year: 1998
Refits: Continuous 2016/2019/2021
Beam: 7.28m (23' 11")
L.O.A.: 33.00m (108' 3")
Gross Tonnage: 193GT
Guest Cabins: 4
Crew: 4
Guests: 8
Max Speed: 22 knots
Cruise Speed:12 knots
Engines: 2 x MTU 8V 396 TE94
Hours: 1900 Since Major Overhaul
Hull Material: Fiberglass
Fuel Capacity: 5,500 gal (20,820 L)
Range: 2500 Nautical Miles
Fresh Water Capacity: 1,600 gal (6,057 L)
Holding Tank: 475 gal (1,799 L)
Location: Florida, Fort Lauderdale, United States
Engines:
MTU Engines Major Service “W5” Overhaul in 2015/2016 Cylinder Heads, Liners, rings, turbos, intercooler, oil Coolers, exhaust replaced, starters and alternators, coolant pumps and injector pumps. Hours at major Service 6900 Hours in 2016 , Jan 2018 she had 7300 hours.
All receipts available upon offer
MTU 2000 Hour service completed June 2021 at 8400 hours
Generators:
Twin Northern Lights 45KW 4 cylinder turbo charged 1800 rpm
Both Generators were completely serviced in 2015 and continuedly maintained
The following is a list of what was done: New Injectors, injector lines, Injection pumps, compression test, Bore Scope, Sea water Pumps, Exhaust elbows and hoses, Hydrostatic engine mounts, turbo chargers
Air Conditioning:
Air Handlers replaced, Starboard Guest Cabin (Dec 2020), Pilothouse Air handler replaced (Dec 2020)
# 2 Chiller compressor replaced (May 2018)
# 3 Chiller replaced (Oct 2019)
Two Chiller Frequency drives replaced (July 2018)
Electrical:
Isolation transformers with Manual Boosting and high low voltage alarm April (2018)
Name Board Lights replaced (Oct 2018) RGBW upgrade
Batteries replaced full force 8D deep cycle (Feb 2021)
Other:
Dive Compressor: New Bauer Oceanus E1 (2017)
Davit: Complete Davit rebuild at Factory (Jan 2021)
The galley has new appliances, new soft goods and the cabinetry was refinished.
The Salon has been updated and upgraded with reupholstered sofas and club chairs, the bar area has been refurbished as well.
All Lighting was updated to dimmable LED
New high end carpet on main deck (2020)
Cabinet hardware was updated for a cleaner look
Most flooring was redone in 2020 with Amtico in Galley and Pilothouse, including new subfloors
All Heads have new glass with new hardware (2017)
Blinds throughout yacht are new (Oct 2020) with new window casings reupholstered.
Updates:
New Teak on swim step and stairs (September 2021)
New Exterior Paint job in 2015, Alwcraft 2000 gets waxed several times a year for the past 5 years by the same company.
Engines major service rebuild “W5” in 2015/2016 Heads, Liners, Rings, Turbos with 1900 hours since Service. In June 2021 a 2000 hour service was performed Including injectors, heat exchangers and Charge air coolers.
Stabilizers received a major service in 2015 including fins upgrade to 16 square feet from 9 sq ft. also the main control was upgraded to the Multisea II (3 term) electronic controls as well as high pressure lines.
Generators major Service in 2015 with oil changes and maintenance consistently done by a very meticulous captain with no spared expense.
Yachtcontroller (Dec 2017) Easy docking and especially when deploying or retrieving a tender.
New Tender and (2) Sea Doo's (2017)
New KVH Satellite TV Antenna (2109)
New Dual Band Access point WIFI Antennas and wiring w/3 wireless extenders for wifi coverage throughout the vessel and ability to put a sim card for use in the Bahamas or Caribbean (2019)
New Custom upgraded highback Stidd Pilothouse helm chair 2 color "Doe/Parfait" (2018)
New Amtico "Fumed Oak" flooring (2018)
New wallpaper in Pilothouse Symphony "Moondance" (2020)
Reupholster Settee "Storm"(2020)
Helm Console Cover reupholstered in Majilite "Destiny Periwinkle" (2018)
(2) Garmin 8500 Chartplotters (2015)
(2) Garmin GMM 17” displays (2015)
(2) Garmin XHD2 Radars (2015)
(2) Garmin remote displays (2015)
Upgraded Stabilizer to Multi-sea control
Upgraded Stabilizer fins to 16 feet
Jog control with rudder control and follow up indicators
New Formica "Portabella" on Pilothoush dash (2018)
Port and Starboard Steps to Bridge refinished (2018)
Steps from pilothouse to flybridge refinished (2018)
New Bronze Mirror behind settee/dinette in pilothouse
Auotopilot
VHF
CCTV Cameras
XM Satellite Weather (2017)
